model | SNE1228BL-LFP | SNE1843BL-LFP | SNE2457BL-LFP | SNE3072BL-LFP | SNE3686BL-LFP |
performance | |||||
Lithlum-lron phosphate(LIFePO4) | |||||
Nominal batlery energy(KWH) | 13.312KWH | 19.968KWH | 26.624KWH | 33.28KWH | 39.936KWH |
Nominal capacty(AH) | 130AH | 130AH | 130AH | 130AH | 130AH |
Nominal vaage(V) | 102.4V | 153.6V | 204.8V | 256V | 307.2 |
Operating vollage Range(V) | 86.4V-115.2V | 129.6V-172.8V | 172V-230.4V | 216V-288V | 259.2V-345.6V |
Module number | 2 | 3 | 4 | 5 | 6 |
Standard charging current(A) | 60A@25℃ | ||||
Max.constart charging cumert(A) | 65A@25℃ | ||||
Standard discharging ourrent(A) | 60A@25℃ | ||||
Ma.constart ducharging cument(A) | 65A@25℃ | ||||
cell techgy | 80% | ||||
Max.constart dicharging cument(A) | BYD Blade Lithlum-Iron phosphate (LIFePO4) | ||||
Design ine | >5000次@80%DOD | ||||
Warranty | 5 years | ||||
Warranty Document Duppted | Yes | ||||
Compatitie hybrid inverters | High voltagehybrid Inverters | ||||
Protection function | |||||
Protection | Over-temperature, over charge, under-voltage, over-current, short circuit alarm Function | ||||
Communication | |||||
Communication | CAN/R5485 | ||||
General data | |||||
Dimension (L’WH)(MM) | 1150*220*845MM | 1150*220*1070MM | 1150*220*1295MM | 1150*220*1520MM | 1150*220*1745MM |
Weight(CG) | 118KG | 165KG | 215KG | 268KG | 325KG |
Shipping state voltage(V) | 3.20-3.30V/CELL | ||||
Sripping status SOC | 20%~30% | ||||
Charging temperature | -20→+55℃ | ||||
Discharging temperature | -30~+60℃ | ||||
term storage ambient temper |
-20-+35℃(<3 months,SOC:20%-60%) | ||||
Long term storage amblent temperature |
-20~+30℃(<1 year,SOC:30%~60%) | ||||
Max. operating atfude | 4,000m(Derating above 2,000m) | ||||
Protection degree | IP21,Indoor Installation | ||||
Retative humidty | 5%-95% | ||||
Cooling | Natural convoction | ||||
Note emisaion | <29db | ||||
Certfication | TUV/CE/IEC/UN38.3/UL1973.. |
