ALL IN ONE design: Highly integrated energy storage inverter, photovoltaic inverter, energy storage battery and energy management system in one unit.
Industrial- grade High Capacity and Long life LiFePO4 Battery Cells: Battery cells with a cycle life exceeding 11000 cycles.
Long term Cost effective Design: Capable o providing household electricity for more than 5 days when fully charged (*).
Supports High-power Photovoltaic Generation: Fully satisfies the requirements for zero-carbon green electricity supply for household self- consumption(**), eliminating the need for high electricity costs.
Versatile Applications: Suitable for PV only, Grid only, PV + Grid, UPS, and PV + Generatorconfigurations.
Simplified Installation: No complex wiringrequired.
Easy Maintenance, User-friendly Operation.
| Model | E1655 | E0836 | |
| Battery | BatteryType | LiFePO4 | |
| Capacity | 16076Wh | 8038wh | |
| Ac Output | outputTopology | LIN+PE | |
| Output Rating | 5500VA | 3600VA | |
| Rated output voltage | 208-240V(Adjustable) | ||
| Waveform | sine wave | ||
| Frequency | 50/60Hz | ||
| overoad Capacity | 10S@110%-130%ad;3s@130%-150%load | ||
| AC Input | Input Topology | L+N+PE | |
| input voltage | 176~264VAC | ||
| inputFrequency | 40~70HZ | ||
| Maxinput curent | MAX 4OA(RMS) | MAX 20A(RMS) | |
| PVInput | PVMaxlnput power | 6000W | 5000W |
| py Max input curent | 28A | 18A | |
| py Max open Circuit voltage | 500VDC | ||
| MpPT voltage Tracking Range | 120~430VDC | 40~450VDC | |
| MPPT Tracking Max Efficiency | 99.50% | ||
| Others | Charging Temperature | 0’C-55 ‘ | |
| Discharge TemperatureUse Ambient Humidity | Max90%RH | ||
| storage Ambient Temperature | .20’C-50’C(15-25’C Best) | ||
| Battery Cycle life | >11000time(70%soc) | ||
| Net weight | about 130kg | about8okg | |
| Size:L’W*H | 670*240*925 mm | 480*240*835 mm | |
| Grade of Protection | IP21 | ||
