  • HBP18-3024
    The HBP18-3024 is a powerful 24VDC, 3000W pure sine wave inverter designed for larger off-grid systems or those with high power demands. It’s ideal for powering heavy-duty appliances, tools, and even some small industrial equipment.
  • Key Features:
  • 24VDC Input: Operates with a 24VDC battery system, suitable for larger solar setups or deep-cycle batteries.
    3000W Rated Power: Provides ample power for high-demand applications.
    Pure Sine Wave Output: Ensures smooth and stable power delivery, compatible with sensitive electronics and motors.
    230V Output Voltage: Standard European voltage output.
    50Hz/60Hz Frequency: Adaptable to various electrical grids.
    High Efficiency: Up to 90% peak efficiency, maximizing power output.
    Applications:
  • Off-grid homes: Powering high-demand appliances like air conditioners, electric heaters, and water pumps.
    Off-grid businesses: Providing reliable power for workshops, small factories, and other industrial applications.
    Large RV and boats: Powering high-power appliances and equipment in larger recreational vehicles and boats.
    Emergency power: Serving as a backup power source for critical equipment during grid outages.
Chat Now
Message
Email

OEM/ODM OS For Office Use Reliable and Efficient Power Source Portable Solar Power Station

Instagram Linkedin Twitter Youtube Facebook
MODEL HBP30-1524 HBP30-2024 HBP30-3024 HBP30-5048 HBP30-6048
LV LV LV LV LV
INVERTER
Rated power 1500W 2000W 3000W 5000W 6000W
Output voltage waveform Pure sine wave
Output voltage regulation 110V/115V/120V±10%
Output frequency 50Hz or 60Hz(±0.2Hz)
Peak efficiency 88%
Nominal DC input voltage   24Vdc        48Vdc
Standby Consumption <2W
PV INPUT
Max solar power input   2500W                                           5000W
PV max charging current 80A
Combined charging current 80A
Max efficiency 98%max
PVarray open circuit voltage 245V
PV Array MPPT Voltage Range 30~230VDC          60~230VDC
AC INPUT
ACinput voltage 120Vac±5%
Acceptable input voltage range 96~132VAC
Nominal input frequency 50Hz/60Hz(Auto detection)
Transfer time 10ms(max)
ACCHARGE
Charging current @Nominal input voltage 25A  30A 40A 35A 40A
Charging Algorithm 4-step  (Li)
OUTPUT
AC output Terminal &Socket(10A max)
LITHIUM BATTERY
Energy 7168wh 14336wh
Nominal voltage 25.6V 51.2V
Battery capacity 280Ah
Standard charging and discharge current 100A
Maximum continuous charging &discharge current 100A
Operation ambient Charge -10~50℃
temperatur Discharge -20~55℃
DIMENSION
Machine Dimension (W*H*D)(mm) 620*865*610 640*992*600
Package Dimension Inverter 617*297*587
W*H*D)(mm) Battery 620*568*610 640*695*600
N.W(kg) Inverte / / 25.6 /                 35.7
Battery / / 115
G.W(kg) nverter / / 27.9 / 38
Battery / / 135
Standard Warranty Inverter:2 years;Lithium battery:5 years
CERTIFICATION     &STANDARDS
Chat Now
Message
Email
MODEL HBP30-1524 HBP30-2024 HBP30-3024 HBP30-5048 HBP30-6048
LV LV LV LV LV
INVERTER
Rated power 1500W 2000W 3000W 5000W 6000W
Output voltage waveform Pure sine wave
Output voltage regulation 110V/115V/120V±10%
Output frequency 50Hz or 60Hz(±0.2Hz)
Peak efficiency 88%
Nominal DC input voltage   24Vdc        48Vdc
Standby Consumption <2W
PV INPUT
Max solar power input   2500W                                           5000W
PV max charging current 80A
Combined charging current 80A
Max efficiency 98%max
PVarray open circuit voltage 245V
PV Array MPPT Voltage Range 30~230VDC          60~230VDC
AC INPUT
ACinput voltage 120Vac±5%
Acceptable input voltage range 96~132VAC
Nominal input frequency 50Hz/60Hz(Auto detection)
Transfer time 10ms(max)
ACCHARGE
Charging current @Nominal input voltage 25A  30A 40A 35A 40A
Charging Algorithm 4-step  (Li)
OUTPUT
AC output Terminal &Socket(10A max)
LITHIUM BATTERY
Energy 7168wh 14336wh
Nominal voltage 25.6V 51.2V
Battery capacity 280Ah
Standard charging and discharge current 100A
Maximum continuous charging &discharge current 100A
Operation ambient Charge -10~50℃
temperatur Discharge -20~55℃
DIMENSION
Machine Dimension (W*H*D)(mm) 620*865*610 640*992*600
Package Dimension Inverter 617*297*587
W*H*D)(mm) Battery 620*568*610 640*695*600
N.W(kg) Inverte / / 25.6 /                 35.7
Battery / / 115
G.W(kg) nverter / / 27.9 / 38
Battery / / 135
Standard Warranty Inverter:2 years;Lithium battery:5 years
CERTIFICATION     &STANDARDS
Model HBP18-1012 Os HBP18-2024 Os HBP18-3024 Os
Nominal Battery System Voltage 12VDC 24VDC 24VDC
INVERTER OUTPUT
Rated power 1000W 2000W 3000W
Output voltage waveform Pure Sine Wave
Output voltage regulation 230V ±5%
Output frequency 50Hz/60Hz(±0.2Hz)
Peak effciency    90%
Nominal DC input voltage 12V(±0.3) 24V(±0.3) 24V(±03)
Standby Consumption <25W
PV INPUT
Max solar power input 900W 1800W 1800W
PV max charging current 60A(±3A) 60A(±3A) 60A(±3A)
Combined charging current 70A(±4A) 80A(±4A) 80A(±4A)
Max efficiency 98.0%max
PV array open circuit voltage 105VDC 145VDC 145VDC
PV Array MPPT Voltage Range 15~105V 30~120VDC 30~120VDC
AC INPUT
AC input voltage 230Vac ±5%
Acceptable inputvoltage range  90-280VAC
Nominal input frequency 50Hz/60Hz (Auto detection)
Transfer time 10ms typical (UPS,VDE;20ms typical (APLI)
AC CHARGE
Charging current @Nominal input voltage 10/20A(±4A) 20A/(±4A) 20A/30A(±4A)
Charging Algorithm 4-step(L)
OUTPUT
AC output 230Vac (Socket*3pcs)
USB TypeC DC output*1pcs
USB-A 5V DCoutput*4pcs
LTHIUM BATTERY
Energy 960Wh       1280Wh 1920Wh       2560Wh 2560Wh
Nominalvoltage 12.8V 25.6V 25.6V
Battery capacity 75Ah        100Ah 75Ah        100Ah 100Ah
Protection board 100A 100A 140A
Standard charging &discharge current 50A          50A 50A         50A 50A
0 p e r a ti o n Charge 0℃ to 45℃
temperature      Discharge 10℃ to 60℃
MECHANICAL SPECIFICATIONS
Dimensions  (W*H*D)(mm) 225*295*363 275*324*403 288*348*490
Shipping Dimensions (WH*D)(mm) / / /
Shipping Weight (kg) /            / /            / /
CERTIFICATION &STANDARDS
CE-EMC+LVD(EN6100-6-3;2007,EN6100-6-1:2017+EN IEC62109-1:2010,EN IEC62109-2:2011)
