| YD600 | ||
| General parameters |
Built-in battery | High quality lithium ion battery |
| battery capacity | 520Wh / 140400mAh /3.7V | |
| AC input | N | |
| input recharging | 120W | |
| solar panel charging | DC5521 160W （13V~26V/8.0A） About 3.8h |
|
| DC Fully Charged Time |
5~ 6 Hours | |
| AC Fully Charged Time |
/ | |
| DC output | USB Port：1 * USB 5V~12V/2A ，QC 3.0； 2 * USB 5V/3.1A; Typ-c Port: 1 * Type-c 5V~20V/3A ; 5521 DC output: 4 * DC 13.5V/6A ; 1 * Cigarette Lighter adapter(13.5V/10A MAX150W) |
|
| AC output | 2 x AC pure sine wave output | |
| AC continuous output power |
600W | |
| Operating temperature of |
-10℃-40℃ | |
| b tt
Product protection |
a.Short circuit protection b.Overcurrent protection c.Overvoltage protection d.Undervoltage protection e.Overload protection f.Over temperature protection |
|
| Package included | 1 x portable solar generator 1 x power adapter 1 x AC line 1 x user manual 1x Car charger |
|
| Machine certification | PSE FCC CE ROHS UL MSDS UN38.3 Air transport report,Marine transportation report |
|
| Adapter parameters |
Output | 24V 5A |
| DC interface | 5521 | |
| shape | Desktop | |
| Input charging function |
Support power adapter charging |
Support |
| Support solar panel charging |
Support | |
| Support car charging | Support | |
| Battery | Battery model specifications |
UTL18650 |
| Single cell capacity | 2600 MAH | |
| Battery series parallel |
6 series 9parallel | |
| Cell voltage | 3.7V | |
| Battery voltage | 22.2V | |
| Battery charge and discharge life |
>1000 times ，Capacity is maintained at approximately 80% |
|
| structure | Product dimension MM | 288*198*166 mm |
| net weight | about 5.9kg | |
| Material | ABS plastic ,plastic shellfire rating 94-V0; |
|
| Product color matching |
Can be freely matched by customers (quantity required: 300 pcs ) |
|
| Product packaging |
Product packaging | Carrying case neutral |
| Carrying case dimension |
39.6*27.6*25.2mm | |
| Single carrying case weight |
about8.0kg | |
| Use scene mode | Applicable to power outages, outdoor operations, night market electricity, emergency rescue, medical, household energy storage, etc. |
|
| Warranty | 12 months warranty | |
