YD600 | ||
General parameters |
Built-in battery | High quality lithium ion battery |
battery capacity | 520Wh / 140400mAh /3.7V | |
AC input | N | |
input recharging | 120W | |
solar panel charging | DC5521 160W (13V~26V/8.0A) About 3.8h |
|
DC Fully Charged Time |
5~ 6 Hours | |
AC Fully Charged Time |
/ | |
DC output | USB Port:1 * USB 5V~12V/2A ,QC 3.0; 2 * USB 5V/3.1A; Typ-c Port: 1 * Type-c 5V~20V/3A ; 5521 DC output: 4 * DC 13.5V/6A ; 1 * Cigarette Lighter adapter(13.5V/10A MAX150W) |
|
AC output | 2 x AC pure sine wave output | |
AC continuous output power |
600W | |
Operating temperature of |
-10℃-40℃ | |
b tt
Product protection |
a.Short circuit protection b.Overcurrent protection c.Overvoltage protection d.Undervoltage protection e.Overload protection f.Over temperature protection |
|
Package included | 1 x portable solar generator 1 x power adapter 1 x AC line 1 x user manual 1x Car charger |
|
Machine certification | PSE FCC CE ROHS UL MSDS UN38.3 Air transport report,Marine transportation report |
|
Adapter parameters |
Output | 24V 5A |
DC interface | 5521 | |
shape | Desktop | |
Input charging function |
Support power adapter charging |
Support |
Support solar panel charging |
Support | |
Support car charging | Support | |
Battery | Battery model specifications |
UTL18650 |
Single cell capacity | 2600 MAH | |
Battery series parallel |
6 series 9parallel | |
Cell voltage | 3.7V | |
Battery voltage | 22.2V | |
Battery charge and discharge life |
>1000 times ,Capacity is maintained at approximately 80% |
|
structure | Product dimension MM | 288*198*166 mm |
net weight | about 5.9kg | |
Material | ABS plastic ,plastic shellfire rating 94-V0; |
|
Product color matching |
Can be freely matched by customers (quantity required: 300 pcs ) |
|
Product packaging |
Product packaging | Carrying case neutral |
Carrying case dimension |
39.6*27.6*25.2mm | |
Single carrying case weight |
about8.0kg | |
Use scene mode | Applicable to power outages, outdoor operations, night market electricity, emergency rescue, medical, household energy storage, etc. |
|
Warranty | 12 months warranty |
