Multiple Operation Modes: The inverters support grid-tied, off-grid with storage backup, and battery-only modes, offering flexibility to adapt to different scenarios.
Safety Features: The inverters incorporate robust safety features, including over-voltage, over-frequency, over-current, over-temperature, and AC short-circuit protection, ensuring safe and reliable operation.
Intelligent BMS: The inverters feature an intelligent battery management system (BMS) that optimizes battery performance and extends its lifespan.
Rated Power: 3600W, 4000W, 4600W, 5000W, 6000W
Nominal Battery System Voltage: 48V
Max. DC Voltage: 500V
MPPT Voltage Range: 120V~500V
Nominal AC Input/Output Voltage: 220/230/240V
Nominal AC Input/Output Current: 15.6A, 17.5A, 20A, 21.7A, 26A
Battery Type: Lead-acid battery / Lithium battery
Max. Charging Current: 75A, 85A, 95A, 100A, 125A
Max. Efficiency: 0.971
Dimensions: 420mm480mm215mm
| MODEL | PH11-3648 | PH11-4048 | PH11-4648 | PH11-5048 | PH11-6048 |
| PRO | PRO | PRO | PRO | PkO | |
| Rated power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal Battery System Voltage | 48V | ||||
| PV INPUT(DC) | |||||
| Maximum recommended DC power | 4000W | 5000W | 5500W | 6000W | 7000W |
| Nominal DC operating voltage | 360V | ||||
| Maximum DC voltage | 500V | ||||
| MPPT voltage range | 120V~500V | ||||
| Maximum input current | 15A/15A | ||||
| No.of MPPtracker | |||||
| Strings per MPP tracker | |||||
| INVERTER INPUT/OUTPUT(AC) | |||||
| Nominal AC input/output power | 3600w | 4000W | 4600W | 5000W | 6000w |
| Nominal input/output voltage;range | 220/230/240V;180-280V | ||||
| AC grid frequency;range | 50/60Hz;45~55/55-65Hz | ||||
| Nominal input/output current | 15.6A | 17.5A | 20A | 21.7A | 26A |
| Maximum input/output current | 16A | 18.1A | 20.8A | 22.7A | 27.2A |
| Inrush current (spike/duration) | 57.5A/5.2us | ||||
| Total harmonic distortion i(THDi) | <3% | ||||
| Powerfactor at rated power | |||||
| Displacement power factor | 0.8leading~0.8lagging | ||||
| Grid type | Single phase | ||||
| BATTERY MODE OUTPUT(AC) | |||||
| Output Rated Power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal output voltage;accuracy range | 230±1% | ||||
| Output ferequency;accuracy range | 50/60Hz (optional)±0.2% | ||||
| Output rated current | 15.6A | 17.5A | 20A | 21.7A | 26A |
| Output waveform | Pure sine wave | ||||
| Peak power | 5400W,10s | 6000W,10s | 6900W,10s | 7500W,10s | 9000W,10s |
| Total harmonic distortion v(linear load) | <3% | ||||
| BATTERY &CHARGER | |||||
| Battery type | Lead-acid battery /Lithium battery | ||||
| Battery voltage | 48V | ||||
| Battery voltage range | 40~60V | ||||
| Charging curve | 3-stage adaptive with maintenance | ||||
| Protection | Over-current protection/Over-temperature protection | ||||
| Maximum charging power | 3600w | 000W | 4600W | 5000W | 6000u |
| Maximu n charging currernt | 75A | 85A | 95A | 100A | 125A |
| EFFICIENCY | |||||
| Maximum effciency | 97.10% | ||||
| Furo-efficiency | 96.50% | ||||
| MPPT effciency | 99.80% | ||||
| PROTECTION DEVICES | |||||
| DC switch rating foreach MPPT;Grid monitoring;Output over curentprotection;Output overvoltage protection-varistor Ground fault monitoring; | |||||
| Integrated all-pole sensitiveleakage current | |||||
| GENERAL | |||||
| Machine Dimension (W*H*D)(mm) | 420*480*215 | ||||
| Package Dimension (W*H*D)(mm) | 610*327*595 | ||||
| N.W(kg) | 30 | ||||
| G.W(kg) | 32 | ||||
| DC connection | H4/MC4 | ||||
| AC connection | Terminal Block | ||||
| Display | LED+LCD | ||||
| Communication interfaces | Wi-Fi/USB/GPRS/RS485 | ||||
| Ingress protection rating | IP65 | ||||
| Humidity | 0~95%RH(No codensing) | ||||
| Operating temperature range | -20℃+60℃With derating above 45℃ | ||||
| Cooling concept | Natura | ||||
| Altitude | <3000m | ||||
| CERTIFICATION &STANDARDS | |||||
| CE-EMC+LVD (EN6100-6-3:2007,EN6100-6-1:2017+EN IEC62109-1:2010,EN IEC62109-2:2011);CE-LVD(EN62477-1:2022);IEC60529;EN50549-1:2019 | |||||
| Poland Type A,(NC RfG:2016,PSE:2018,PTPiREE:2021);C10/C11;UNE217001-2020;UNE217002-2020,NTS-631:2021(Type A);G98+G99 | |||||
| MODEL | PH11-3648 | PH11-4048 | PH11-4648 | PH11-5048 | PH11-6048 |
| PRO | PRO | PRO | PRO | PkO | |
| Rated power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal Battery System Voltage | 48V | ||||
| PV INPUT(DC) | |||||
| Maximum recommended DC power | 4000W | 5000W | 5500W | 6000W | 7000W |
| Nominal DC operating voltage | 360V | ||||
| Maximum DC voltage | 500V | ||||
| MPPT voltage range | 120V~500V | ||||
| Maximum input current | 15A/15A | ||||
| No.of MPPtracker | |||||
| Strings per MPP tracker | |||||
| INVERTER INPUT/OUTPUT(AC) | |||||
| Nominal AC input/output power | 3600w | 4000W | 4600W | 5000W | 6000w |
| Nominal input/output voltage;range | 220/230/240V;180-280V | ||||
| AC grid frequency;range | 50/60Hz;45~55/55-65Hz | ||||
| Nominal input/output current | 15.6A | 17.5A | 20A | 21.7A | 26A |
| Maximum input/output current | 16A | 18.1A | 20.8A | 22.7A | 27.2A |
| Inrush current (spike/duration) | 57.5A/5.2us | ||||
| Total harmonic distortion i(THDi) | <3% | ||||
| Powerfactor at rated power | |||||
| Displacement power factor | 0.8leading~0.8lagging | ||||
| Grid type | Single phase | ||||
| BATTERY MODE OUTPUT(AC) | |||||
| Output Rated Power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal output voltage;accuracy range | 230±1% | ||||
| Output ferequency;accuracy range | 50/60Hz (optional)±0.2% | ||||
| Output rated current | 15.6A | 17.5A | 20A | 21.7A | 26A |
| Output waveform | Pure sine wave | ||||
| Peak power | 5400W,10s | 6000W,10s | 6900W,10s | 7500W,10s | 9000W,10s |
| Total harmonic distortion v(linear load) | <3% | ||||
| BATTERY &CHARGER | |||||
| Battery type | Lead-acid battery /Lithium battery | ||||
| Battery voltage | 48V | ||||
| Battery voltage range | 40~60V | ||||
| Charging curve | 3-stage adaptive with maintenance | ||||
| Protection | Over-current protection/Over-temperature protection | ||||
| Maximum charging power | 3600w | 000W | 4600W | 5000W | 6000u |
| Maximu n charging currernt | 75A | 85A | 95A | 100A | 125A |
| EFFICIENCY | |||||
| Maximum effciency | 97.10% | ||||
| Furo-efficiency | 96.50% | ||||
| MPPT effciency | 99.80% | ||||
| PROTECTION DEVICES | |||||
| DC switch rating foreach MPPT;Grid monitoring;Output over curentprotection;Output overvoltage protection-varistor Ground fault monitoring; | |||||
| Integrated all-pole sensitiveleakage current | |||||
| GENERAL | |||||
| Machine Dimension (W*H*D)(mm) | 420*480*215 | ||||
| Package Dimension (W*H*D)(mm) | 610*327*595 | ||||
| N.W(kg) | 30 | ||||
| G.W(kg) | 32 | ||||
| DC connection | H4/MC4 | ||||
| AC connection | Terminal Block | ||||
| Display | LED+LCD | ||||
| Communication interfaces | Wi-Fi/USB/GPRS/RS485 | ||||
| Ingress protection rating | IP65 | ||||
| Humidity | 0~95%RH(No codensing) | ||||
| Operating temperature range | -20℃+60℃With derating above 45℃ | ||||
| Cooling concept | Natura | ||||
| Altitude | <3000m | ||||
| CERTIFICATION &STANDARDS | |||||
| CE-EMC+LVD (EN6100-6-3:2007,EN6100-6-1:2017+EN IEC62109-1:2010,EN IEC62109-2:2011);CE-LVD(EN62477-1:2022);IEC60529;EN50549-1:2019 | |||||
| Poland Type A,(NC RfG:2016,PSE:2018,PTPiREE:2021);C10/C11;UNE217001-2020;UNE217002-2020,NTS-631:2021(Type A);G98+G99 | |||||
