Solar panels/800W SOLAR SYSTEM SETUP /YH110W-18M

Key Features:

8 x 110W Flexible Solar Panels: These panels are lightweight, durable, and can be easily mounted on curved surfaces like RVs or boat roofs.
Micro Inverter: Each panel is connected to a micro inverter, which optimizes energy production and provides independent monitoring for each panel.
Easy Installation: The system is designed for easy setup, with clear instructions and pre-wired components.
Reliable Performance: The panels are built with high-quality materials and are designed to withstand harsh weather conditions.
Application:

Off-grid living: Powering basic appliances and electronics in remote cabins or off-grid homes.
RV and boat power: Supplementing or providing primary power for RVs and boats.
Portable power: Providing power for camping, outdoor activities, or emergency situations.
Key Parameters:

Peak Power: 880W (8 x 110W)
Open Circuit Voltage (Voc): 11.76V per panel
Short Circuit Current (Isc): 11.76A per panel
Maximum Power Voltage (Vmp): 10.06V per panel
Maximum Power Current (Imp): 10.94A per panel
Module Efficiency: 17.83%
Dimensions: 730mm x 845mm x 2.5mm per panel
Weight: 2.3kg per panel

Solar panels/800W SOLAR SYSTEM SETUP /YH110W-18M

ELECTRICAL DATA
Model Type YH110W-18M
Peak Power(Pmax) 110
Maximum Power Voltage(Vmp) 10.06V
Maximum Power Current(Imp) 10.94A
Open Circuit Voltage(Voc) 11.76V
Short Circuit Current(Isc) 11.76A
Module Efficiency(%) 17.83
* STC: irradiance 1000 W/m2, AM 1.5G, and cell temperature of 25°℃
THERMAL CHARACTERISTICS & OPERATING CONDITIONS
Maximum System Voltage(V) 1000
Maximum Series Fuse Rating(A) 10
Power Tolerance 0~+3%
Pmax Temperature Coefficients(W/°℃) -0.350%
Voc Temperature Coefficients(V/C) -0.270%
Isc Temperature Coefficients(A/℃) +0.048%
NOCT Nominal Operating Cell Temperature(℃) 45±2
Operating and Storage Temperature(°℃) -40~+85
MECHANICAL CHARACTARISTICS
Cell Type 166*83Mono
No. of Cells 36(4×9)
Dimensions 730*845*2.5mm
Weight 2.3kg
Junction box IP67
Output cables 4mm2-90cm cables+mc4
MaxWind Load/Snow Load 2400Pa/5400Pa
Packing way
20FT 240sets
40HQ 580sets



ELECTRICAL DATA
Model Type YH110W-18M
Peak Power(Pmax) 110
Maximum Power Voltage(Vmp) 10.06V
Maximum Power Current(Imp) 10.94A
Open Circuit Voltage(Voc) 11.76V
Short Circuit Current(Isc) 11.76A
Module Efficiency(%) 17.83
* STC: irradiance 1000 W/m2, AM 1.5G, and cell temperature of 25°℃
THERMAL CHARACTERISTICS & OPERATING CONDITIONS
Maximum System Voltage(V) 1000
Maximum Series Fuse Rating(A) 10
Power Tolerance 0~+3%
Pmax Temperature Coefficients(W/°℃) -0.350%
Voc Temperature Coefficients(V/C) -0.270%
Isc Temperature Coefficients(A/℃) +0.048%
NOCT Nominal Operating Cell Temperature(℃) 45±2
Operating and Storage Temperature(°℃) -40~+85
MECHANICAL CHARACTARISTICS
Cell Type 166*83Mono
No. of Cells 36(4×9)
Dimensions 730*845*2.5mm
Weight 2.3kg
Junction box IP67
Output cables 4mm2-90cm cables+mc4
MaxWind Load/Snow Load 2400Pa/5400Pa
Packing way
20FT 240sets
40HQ 580sets
