Key Features and Specifications:
Rated Power: 3600W
Capacity: 3072Wh
Battery Type: LFP (Lithium Iron Phosphate)
Battery Life Cycle: >4000 times (80% capacity retention)
Charging Options: AC, EV, Solar (MPPT)
Output Ports:
AC Outlets: 1800W
EV Input: 1800W
Car Charger: 192W
Solar Charger: 1500W
USB-C: PD100W x 2
USB-A: 18W x 4
DC Output: 120W
Output Waveform: Pure Sine Wave
Output Voltage: 110V-120V / 220-240V
Output Frequency: 50/60Hz
Dimensions: 563 x 372 x 423mm
Weight: 46kg
Warranty: 12 months
| F series Portable Power Energy Storage | ||||
| Model Picture | ||||
| F3600 | F3600X | |||
| Rated AC Output | 3600W | / | ||
| Capacity | 3072WH | 4608WH | ||
| Bettery Type | LFP | |||
| Battery cycle life | >4000 times ，Capacity is maintained at approximately 80% | |||
| UPS/EPS（ <10ms) | Y | / | ||
| LCD Display | Y | / | ||
| Housing Material | ABS | |||
| Charging Temperature Range | Discharge:-20-45s℃ Charge:0-45℃ | |||
| Charge Way |
AC Input | 1800W | / | |
| EV Input | 1800W | / | ||
| Car Charge | 192W | 192W | ||
| Solar Charge (MPPT) | 1500W | 800W | ||
| Charge Time |
Wall charge(EU) | About 2hours | / | |
| EV Input | About 2hours | / | ||
| Car Charge Time(EU) | About 16 hours | About 16hours | ||
| Solar Charge Time(EU) | About 2hours | About 5-6 hours | ||
| USB Output | USB-Type-C | PD100W*2 | PD60W* 1 | |
| USB-A | 18W*4 | 18W* 1 | ||
| DC port Output | 5521*2 | 5521* 1 | ||
| Cigarret Lighter Output | 120* 1 | 120* 1 | ||
| RV输出 | 360W | / | ||
| LED Light | 1W | / | ||
| AC Output | Output waveform | pure wave sine | / | |
| Output voltage | 110V-120V 220-240V | / | ||
| Output frequency | 50/60HZ | |||
| AC continuous output | 3600W | / | ||
| Peak AC output | 7200W | / | ||
| Discharging Temperature Range | Charging temperature: 32to104℉(0to40℃) Discharge temperature: 14to104℉(-10to40℃) Storage temperature: -4to113℉(-20to45℃) |
|||
| Authentication | UL FCC,CE ROSH,PSE UN38 .3,SAA,UKCA | |||
| Product Size | 563*372*423MM | 563*372*423MM | ||
| Weight | 46KG | 49.3KG | ||
| Warrantly | 12 months | |||
| Color | Blank+Orange | |||
| Accessories | AC CABLE user’s manual * 1 |
AC CABLE user’s manual * 1 |
||
